Name: Smart Home Lighting Control Unit Relay Switch Module 8 Way 16A In Line With RS485 Modbus Protocol
Brand: Jetacon Technology Limited
SKU: L-S-16
Price: 149.99 USD
Availability: InStock

Home Products Terminal Power Supply

Smart Home Lighting Control Unit Relay Switch Module 8 Way 16A In Line With RS485 Modbus Protocol

Product Details:

Place of Origin:	China Mainland
Brand Name:	Jetacon
Certification:	CE
Model Number:	L-S-16

Payment & Shipping Terms:

Minimum Order Quantity:	3 Pieces
Price:	US $149.99
Packaging Details:	Standard Export Carton
Delivery Time:	7-15 days
Payment Terms:	T/T, L/C, Paypal, Payoneer
Supply Ability:	100 /Pieces per Day

Contact Now

Detailed Product Description

Channel:	16	Voltage Output:	DC24V
Current Output:	16A

Function Description:

Din Rail Mounting
8 Relay open Close ports
Can have up8Separate areas
Each Channel Having a lamp protection delay
Each channel start with a delay
Each channel Have Overload protection
Each channel Start button has priority
Fire has played a strong function (need fire protection system provides normally open dry contact signal)
Each Channel has a status indicatorLED
Overheating protection function
Can Remote programming and management

parameters:
Working conditions	Voltage	DC24V	Load capacity	Number of Channels	8 channel
	Power	30mA ~ 450mA		Load voltage	AC250V
	Temperature	-20 ~ 60		Load current per channel	16A (resistive)
	Relative humidity	20% to 90% (non-condensing)		Overload	Have
Storage conditions	Temperature	-30 ~ 70	Other	Signal	Modbus / RS485
Storage conditions	Relative humidity	20% to 93% (non-condensing)	Other	Dimensions	72mm × 68mm × 62mm
